Specifications

Unit

X5746

X5746A

Table size

mm

460x1235

460x1600

T-slots(NO./width/pitch)

mm

5*18*80

Table travel (X/Y/Z)

mm

900/650/450

1200/650/450

Swivel angle of milling head

-

360°

Spindle taper

-

ISO40

Spindle speed range

r.p.m

(27) 30-2050

Table feed(X/Y/Z)

mm/min

10-1000/10-1000/6-640

Table rapid speed

2200/2200/1100

Distance between spindle nose and table surface

mm

32-482

Distance from spindle center line to column

mm

47-697

Main motor power

Kw

5.5

Feed motor

Kw

AC servo motor  X/Y:15NM; Z: 18NM

Max load

Kg

800

Overall size

mm

2570x2035x1990

2570x2460x1990

weight

kg

3600

4000
